Layar Model and Yahoo Pipes

layar://georssgateway?SEARCHBOX=http://tinyurl.com/28fpofc&SEARCHBOX_2=-
33.918209&SEARCHBOX_3=151.227871

layar://georssgateway?SEARCHBOX=http://tinyurl.com/28fpofc&SEARCHBOX_2=-
33.918281&SEARCHBOX_3=151.228134

http://tinyurl.com/28fpofc

Final Vitra Model

Internal shot of the model will the materials added, but with no furniture, i plan to do the furniture within 3ds max, my next step will be putting the model into layar and finding it in the site location at uni.


These are some images of the final Vitra Outlook on sketch up with all the materials added, in the later stages i will be exporting my model to 3ds max to reduce the poly count and putting some rendered views on my blog, the choice of materials or combination of materials is a question, there might be some materials i could be changing.

Week 12 Independent Task - Model

This is an internal shot of the model, the above ceiling with windows are elevated to its original positioning, down lights will be used to get more out of the building, notice i havent put any furniture or anything, this will be done in the later stages of the model.



These are some final images of the Vitra Outlook, but within these images i havent added any materials, just a white model, the next stage im going to be applying the images in sketch up and then importing the model to 3ds max to do some rendered views of the model.
Above are angled, top, and side views, within these views i tried to enhance the original shapes and keep them at its original state, in a digram will be showing the original model and the pieces that i took from the model.

Week 12 - Studio Task - 500 Word Text

The Vitra Outlook

The Vitra Outlook, design inspired by one of many architects, Frank Gehry.
With his design of the Vitra Design Museum, two of the main elements were taken from the Museum to design the Vitra Outlook, many styles and shapes were implemented into that museum so therefore experimentation of the combination of styles was of great importance to its contribution of the design.

Situated within the rocky canyons of the desert, the Outlook provides remote and ashtonishing views for the home dweller, the home can mainly be constructed upon rocky cliffs and remote open area locations. With the surrounding environments open desert type area with the ocean just at the bottom of the cliffs, also with the rocky surroundings and harsh look of minor vegetation.
It gives the home owner a sense of persoal space and open type feeling.

The external components to the house itself is made from different type of materials, but all mainly recycable, the wall cladding itself is made from a hardwood timber that treats itself was a type of water-proofing for wet weather, the rubber is used under the wall cladding also used as a water method for no water penetration. The external construction itself is made up in a way where it stands out from the surrounding environment.

Internally as said before, the construction is made up in one storey the east part of the home the bedroom and other amenities while the other the kitchen, family lounge rooms and overlooking outdoor views, the main access to this home is located under the bigger part of the building, under is a outdoor stair case that has been mounted upon a large concrete structure, this is used as a form of support for the main building itself.
The stairs itself is made of an aluminium material that reacts as a non slip material.
The rest of the house itself is all divided up to its allocated sections to provide major sunlight during the winter and minor sunlight during the summer.

Overall the building itself with its contemporary design is something different but in many ways a home that stands out, in relation to the Vitra Design Museum the minor aspects that have been taken from the main building itself has not kept its original shape, but has been extruded and edited in a minor may.
As final the Vitra Outlook offers the modern design that catches attention to the human eye.

Week 11 - A1 Montage

These are just some sample draft posters of my layouts that i plan to use, within my final design i plan to enhance my design by just using these layouts as a guide, rendered views of the model will be done in 3ds max to create a more real type of environment, also the text and videos will be edited to suit the posters design.




These are just a bunch of ideas for my design of the Vitra Outlook, will the combination's of all materials and images i have found and researched.

Week 11 - Independent Task - Draft ideas

With these two images, the above and the bottom are my ideas that were set for the model, i had an idea to create a home that is canter levering off the end of the cliff, the images with my montage is where i had got my theme from, with these selected components of the model, i plan to embed and create the home.
These are just some minor ideas of my model, in the later stages i will be presenting more of my progressing model.

___________________________________________________________________

This is an overall image of the design, within my research of different type of homes on the internet, ive decided to call it the Vitra Outlook, for the home will be situated upon a rocky type cliff that i will be modeling in crysis and exporting the design of the home to the engine.
Most of the materials chosen to design this building will be implemented in the later stages.

The internal part of the model, within the internal part i dont plan to model everything, just the main fixtures such as bathroom fixtures and some minor elements, there will be more internal shots of the Vitra design, showing most of its layout and style.

This is a shot of the progressing model, there are some feature that i have changed due to its problematic shape, but this i had overcome, within this shot is on section of the home, within this curved shaped layout will be a kitchen/ relaxing dining area, some of the window types have been constructed.

This is my starting basis of the model, there were only 2 shapes i chose to take from the original Vitra to design my house, the 2 shapes are taken in the shot above both having there differences in design layout and style, with this i am going to incorporate the materials chosen onto the model to design a lighthouse type home.

Week 11 - Studio Task - A1 Indesign Poster Layouts

Source:
http://www.dominicbusby.com/typographicwalks.html

Source:
http://www.sfmoma.org/artwork/109627

These are just some poster designs from the internet, in which i plan to merge the ideas to create posters similar to these designs, below are the simple layouts presented for the design.

Red area will contain, main heading and also
information on the design, the green areas
will have still images, the blue area will contain
the animation, while the black background
will have an overall image.

Black specify s the overall image of the design whilst,
any where on the black area will have some text
red has the main title of the project, green contains
still images and the blue will have images and a video.

Black will have the main image, red has the main title
two of the green boxes will contain still images while
one box will have the animation, while the main text
can be placed anywhere on the black area.

Final Textures

My ideas with these abstract textures is to create with them an abstract house, with the inspiration of Kendrick Bangs Kellogs and the form of his buildings, i plan to create a home that is blended in with the surrounding environment, that is cantilevered and raised from the ground.
In relation to these textures, they all have there different type of design and formation so therefore constructing these elements into the model should create something different.
